B.O.D. INCUBATOR

(Low Temperature, Super Deluxe Digital Model) Most versatile for Biochemical Oxygen Deand determinators. Castor wheel mounted cabinet is double walled with inner chamber S.S. and outer wall of M.S. Sheet duly powder coated. The gap of 75 m.m. between the outer and the inner wall is fitted with special grade glass wool to prevent thermal losses. Triple walled back of the unit is fitted with two air circulating fans for maintaining temperature uniformity throughout the chamber, Fully view inner glass / Acrylic door permits inspection of specimens, without disturbing the same. Look and key arrangement is provided in the double walled outer door. Unit is fitted with door operated illumination lamp inside the chamber. Refrigeration unit is formed by ISI marked compressor, The front panel is provided with separate indicator lamps for main , heating and incoming voltage. Supplied complete with 3 shelves, cord and plug to work on 220/230 A.C. supply. Temperature From 5.C to 50.C is controlled by MICRO PROCESSOR ELECTRONIC DIGITAL TEMPERATURE INDICATOR CUM CONTROLLER withan accuracy of = 0.5*C. SUPER DELUXE DIGITAL MODEL CAPACITY S.S.(304 Grade) A) 455 x 610 x 410 mm (18” x 24” x 16”) 4 Cu ft (112 ltr) B) 505 x 830 x 415 mm (20” x 34” x 17”) 6.1 Cu ft (171 ltr) C) 570 x 875 x 550 mm (23” x 35” x 22”) 10 Cu ft (280 ltr) D) 650 x 900 x 550 mm (26” x 36” x 22”) 12 Cu ft (336 ltr) OPTIONAL ACCESSORIES A) Interior illumination with 3nos. fluorescent tubes (temp.10* to 50*c) B) Automatic Voltage Stablizer 3 KVA. (TRIPLE RELAY) C) All S. Steel Body 304/202 grade for GMP Standard .............................P.O.R.
